Mark a finish map
Identify cosmetic faces, sealing faces, threaded features, contact areas and masked zones on the drawing. A single color or finish name does not tell the finishing partner which surfaces must be protected.
MATERIAL PURCHASING & PROCESS GUIDE
Material & Surface Finish Compatibility
Connect the substrate to the finish specification and the delivered dimensions. OUJI coordinates finishing through specialist partners; the exact grade, geometry and acceptance requirement determine the route.
SPECIFICATION REFERENCE
Choose a finish route with its conditions.
This matrix is a review aid, not blanket approval for every alloy and coating. Use it to identify which finish, surface map and inspection stage belong in the RFQ.
| Substrate | Route to review | Condition that changes the order | Finished-part acceptance | Reference / next step |
|---|---|---|---|---|
| Aluminum | Anodizing, including hard anodizing where specified | Alloy and temper, process/type, color, thickness, sealing and masking; appearance varies by alloy | Mark fits and cosmetic surfaces accepted after treatment; do not use one universal allowance | Aluminum Anodizers Council (opens in a new tab) |
| Stainless steel | Passivation | Exact grade, treatment specification and required verification; passivation is not a decorative plated layer | Define cleanliness and surface acceptance separately from dimensional inspection | ASTM A967/A967M scope (opens in a new tab) |
| Steel | Drawing-specified protective finish | Name the coating and thickness; identify threads, bores and areas to mask | State whether the final fit is measured after coating and whether a coating report is required | OUJI finishing review |
| Brass or copper | Specified plated or as-machined surface | Identify the substrate alloy, coating stack and contact faces that must remain exposed | Separate cosmetic appearance from conductivity or other functional acceptance tests | OUJI finishing review |
| PMMA or polycarbonate | Machined appearance / selected optical finishing | Specify the polymer formulation, viewing faces, internal access and approved cleaning exposure | Use a defined visual or optical criterion; a clear stock name does not establish a polished result | Acrylic surface requirements |
| PEEK, POM, nylon or PTFE | As-machined finish; special treatment by formulation review | Do not transfer a metal finishing specification to a polymer; define functional surfaces and conditioning | Inspect dimensions in the agreed material and temperature condition | Ensinger machining guidance (opens in a new tab) |
Accept the dimension after the final operation
If a fitted bore is specified after coating, make that inspection stage explicit. Coating growth, pretreatment and any later machining must be considered together; this page does not prescribe a universal thickness compensation.
Use the published sequence as evidence
OUJI’s selective-machining-after-black-anodizing project documents one operation sequence. Its scope does not establish the alloy or finish behavior of a different part. Review the original case and specify the new drawing’s protected areas.
RFQ example: identify the substrate and condition; name the finish specification; mark masking and cosmetic faces; highlight all dimensions that apply after finishing.
