Stock grade versus resin designation
Confirm the datasheet applies to the rod or plate being supplied. A molding-resin document should not silently replace the specification for a machined stock shape.
Engineering plastic / CNC MATERIALS
PEI / Ultem CNC Machining
Also known as: Polyetherimide
Machined PEI components to the specified formulation, including Ultem 1000 and 2300 requirements for review.
CNC milling & turning · Drawing-based orders
Ultem 1000 or 2300: is reinforcement part of the drawing?
Keep the full PEI formulation. Unfilled Ultem 1000 and glass-filled grades such as 2300 should not share one generic strength, appearance or compliance claim. Quote the actual machinable stock and required documentation; the brand name is only one part of the specification.
01 / MATERIAL SPECIFICATION
PEI / Ultem grades & conditions.
Match the full designation on your drawing. Frequent machining experience, published project evidence and specifications for review are shown separately.
| Grade / designation | Experience | Include with your drawing | Inquiry |
|---|---|---|---|
| Ultem 1000 | Specify for review | Ultem 1000: identify the unfilled PEI stock grade and any mandatory manufacturer documentation. | Quote grade ↗ |
| Ultem 2100 | Specify for review | Ultem 2100: preserve the 10% glass-filled designation and the required stock form. | Quote grade ↗ |
| Ultem 2300 | Specify for review | Ultem 2300: retain the 30% glass-filled formulation and identify orientation-sensitive dimensions. | Quote grade ↗ |
| Static-dissipative PEI | Specify for review | Static-dissipative PEI: specify the manufacturer product and electrical acceptance range and test conditions. | Quote grade ↗ |
Listed grades do not imply current inventory. Material condition, stock form and documentation are agreed with the quotation.
02 / MACHINING REQUIREMENTS
Make the drawing ready for review.
Focus on the details that change material purchasing, the machining route and finished-part acceptance.
Thin sections and residual stress
Show slender walls and deep material removal. Include any specified conditioning or stress-relief step and identify when final dimensional inspection should occur.
Electrical and fire requirements
Where the buyer requires electrical behavior or a flammability rating, give the test basis and documented product grade. A general PEI characteristic is not finished-assembly approval.
ORDER DETAILS
Material, finish and documentation.
Specify the requirements together so the quoted scope matches the finished part you need.
Purchasing
Material certificates ↗
Specify the material records and traceability your order needs.
ManufacturingFinish compatibility ↗
Connect material, coating and final dimensional requirements.
SpecificationGrade cross-reference ↗
Review regional names without assuming an automatic substitute.
Finishing is coordinated through specialist partners. View surface finishing services.
Does “Ultem” identify a single machining material?
No. Keep the grade number and reinforcement in the purchase specification. Unfilled, glass-filled and static-dissipative products need their own stock and property review.
Can PEI use the same thermal limit as PEEK?
Use the manufacturer data for the selected PEI formulation and the relevant test or service condition. A temperature published for a PEEK product cannot establish the acceptance limit for PEI.
DRAWING TO QUOTATION
Have a material on your drawing?
Send the drawing and quantity. We’ll review the material, machining route, finish and inspection requirements together.
Response within 24 hours of receiving complete project details.
Start with what you have.
Open the full request form ↗Details already in your drawing do not need to be repeated. If a material is undecided, tell us what the part needs to do.
See our inspection approach ↗
